Page 10

























POS LOM Ref # ORIGINAL CODE DESCRIPTION

1   T07135390200 AMADAŽ LENS Ř1.5 FL5.0 ASSY
  MD7136096900 AMADAŽ LENS Ř1.5 FL7.5 ASSY
    AMADAŽ MOUNT FOR LENS Ř 1.5


2   71360261 AMADAŽ GASKET TEFLON - LENS HOUSING Ř1.5

3   MD7110965200-71366182 AMADAŽ LENS Ř2.0 FL5.0 ASSY
  MD7110965300-71368467 AMADAŽ LENS Ř2.0 FL7.5 ASSY

  MD7110965400 AMADAŽ LENS Ř2.0 FL 10 ASSY
    AMADAŽ MOUNT FOR LENS Ř 2.0


4   T07110968000 AMADAŽ LENS Ř1.5 FL5.0 HP ASSY FOR F.O.
  T07110968100 AMADAŽ LENS Ř1.5 FL7.5 HP ASSY FOR F.O.
    AMADAŽ MOUNT FOR LENS Ř1.5 F.O. ALUMINIUM


5   71361393 AMADAŽ GASKET TEFLON - LENS HOUSING Ř2.0

6     AMADAŽ Ř 1.5" FL5.0" ET 7.4MM MENISCUS MP5 ASSY FO NT
  71501072 - 11040081 AMADAŽ Ř 1.5" FL5.0" ET 7.6MM PO/CX ASSY FO NT
  71501070 AMADAŽ Ř 1.5" FL7.5" ET 7.6MM PO/CX ASSY FO NT
  71502030 AMADAŽ Ř 1.5'' FL10.0'' ET7.6MM PO/CX ASSY FO NT
    AMADAŽ MOUNT FOR LENS FL 5.0" FO NT
    AMADAŽ MOUNT FOR LENS FL 7.5" FO NT



7   71501071 AMADAŽ GASKET FOR LENS FO NT
